crossthreaded spark

Forum rules
Please can you post items for sale or wanted in the correct For Sale section. Items / bikes for sale here will be removed without warning. Reasons for this are in the FAQ. Thanks
Evilchicken0
Site Supporter
Site Supporter
Posts: 5374
Joined: Tue Apr 29, 2008 8:59 pm
Bike owned: Bimota SB6 Yamaha FZR 3TJ x2
Location: Lundin Taan
Re: crossthreaded spark

Post by Evilchicken0 »

There are a few bits on the bay but mainly on USA ....

There's a nice red / white tail for £50 though
suzkistorey
Settled in member
Posts: 21
Joined: Wed Aug 13, 2014 7:04 pm
Bike owned: FZR400
Re: crossthreaded spark

Post by suzkistorey »

cheers i'll have a look on the usa version to see if I can get anything, was looking at the old cheap Chinese ones but not sure if its worth the risk of cheap tat.

is the 600/750/1000 interchangeable with the 400?
willandrip
Site Supporter
Site Supporter
Posts: 983
Joined: Sun Aug 14, 2011 8:33 am
Bike owned: Far, far too many now
Location: North Tyneside Tyne and Wear
Re: crossthreaded spark

Post by willandrip »

You can fit a 600 3HE nosecone and fairing side panels on a Genesis and make it look acceptable.
The birdcage requires altering as the original mirror stay mount arms are in a different place.


There is nothing wrong with the Chinese panels that a bit of fettling wont cure..
A contributor on here, Kayla850, got some painted in her own design and I could not fault the finish.
You could not buy the paint for what they cost.
A red box doth not a Snap On make.
suzkistorey
Settled in member
Posts: 21
Joined: Wed Aug 13, 2014 7:04 pm
Bike owned: FZR400
Re: crossthreaded spark

Post by suzkistorey »

brill, thanks, will take a look.
evoluzione750
Settled in member
Posts: 21
Joined: Sun Jan 18, 2015 12:55 am
Bike owned: NC27, 3EN1, GK75A, NC29
Location: Oxfordshire, UK
Re: crossthreaded spark

Post by evoluzione750 »

I came across a mangled plug thread on my bike as well and thought I'd share my solution to anyone who also has the problem. I took an old spark plug that fits the bike and turned it into a tap as I didn't have any taps that fit the plug thread. Turning it into a tap just involved cutting a groove in the threads of the plug.

To prep the bike, I made sure the exup valve was open, rotated the crank until the exhaust valves were open on the affected cylinder, took the end can off, stuck a rubber fitting snugly in the pipe with about 5 psi to blow any swarf out the plug hole not caught by the tap wax.

When I was cutting it, I made sure to back the tap out completely a couple times to blow out any shavings. Afterwards, the plug went in silky smooth. I'll post a picture of the plug tap I made if I can find it laying around the shop.
Evilchicken0
Site Supporter
Site Supporter
Posts: 5374
Joined: Tue Apr 29, 2008 8:59 pm
Bike owned: Bimota SB6 Yamaha FZR 3TJ x2
Location: Lundin Taan
Re: crossthreaded spark

Post by Evilchicken0 »

That shows some great thinking :peace:
